Project: AUGREEN

Being the winner of the Platinum Award of CIC Green Product Certification - HK G-PASS, AUGREEN Block System is among the very few wall partitions which meets users demand for flexibility and versatility in Hong Kong.

AUGREEN Blocks act as natural air quality regulators to maintain comfortable indoor temperature and relative humidity. AUGREEN Blocks are integrated solution for fulfilling various requirements such as high quality of products and services, shorter project time, lower costs, safer sites, better appearance, faster and easier installation and simpler coordination.

Installation Demonstration and Features

Light Weight

Gypsum is a light-weight material that weighs less than half of the weight of cement, making AUGREEN Blocks easier to be transported. The total dead load of a 20-story building is estimated to be over 1,000 tonnes less than a cement building.

Space Saver

AUGREEN Blocks are made to be light and thin, compared to a 100mm-thick concrete wall with 2 layers of 15mm-thick plastering, AUGREEN Blocks save 50mm with an 80mm-thick wall. Thinner walls also mean that the practical area in a building will be enlarged.

Tough and Strong

AUGREEN Blocks may be light and thin, however, a 100mm-thick AUGREEN Block can be built up to 7-metre high & 150mm-thick AUGREEN Block can be built up to 8-metre high without any steel stiffeners. No door / opening lintels are required for openings less than 2-metre wide.

Sound Insulation

AUGREEN walls are sound-proof; an 80mm-thick AUGREEN Block Wall can achieve an equivalent sound insulation performance of a 100mm-thick concrete wall. 58 Sound Transmission Class (STC) can be achieved by two 80mm+20mm rock wool.

Fire Resistance

Safety is one of our first priorities, our 80mm and 100mm/150mm AUGREEN Blocks have passed the 2 hours and 4 hours Fire Resistant Poly (FRP) test respectively.

Quick Installation
AUGREEN Blocks are easy to be moved due to its size and light-weight features, they are also very easy to install. No plastering, no steel frames, accesses can be chased afterwards, AUGREEN blocks can be installed 50% faster compared to concrete blocks, which require plastering, steel framing and rubbish handling. 15-20m² can be built per man day and painting works can start 2-3days after the building of AUGREEN Block walls.

Environmental-Friendly

As the 1st wall partition in Hong Kong, AUGREEN Block Wall System is very honoured to receive numbers of sustainability awards including the “Merit Award” of Building Product Section of Green Building Award 2012 and the “Green Innovation Awards” of Hong Kong Awards for Environmental Excellence (HKAEE).

Load-bearing

AUGREEN Blocks are very rebust and allows users to decorate the way they want. AUGREEN Blocks has a Shear Stress of 1.4MPa and a Tensile Strength of 1.4-2.5MPa, each anchor can bear up to 100lbs.

AUGREEN Block Wall System	Standard Blocks	Water Repelling Blocks	High Density Blocks	High Density Water Repelling Blocks
Model	SB75 / SB80 / SB100 / SB150	WR80 / WR100 / WR150	HD80 / HD100 / HD150	HW80 / HW100 / HW150
Density	Around 900 kg/m³		Around 1,200 kg/m ³
Source of Material	Gypsum
Format	75 / 80 / 100 mm : 666 mm x 500 mm (3 blocks = 1 m²) 150 mm : 333 mm x 500 mm (6 blocks = 1 m²)
Thickness	80 mm, 100 mm, 150 mm
Dimensions Tolerance	Length : ± 2.5 mm, Height : ± 1.5 mm, Width : ± 0.5 mm
Weight	75 mm : 22.5 kg /80 mm : 25 kg / 100 mm : 30 kg / 150 mm : 22.5 kg		80 mm : 35 kg / 100 mm : 40 kg / 150 mm: 30 kg
Colour	Grey White	Blue	Yellow	Green
Fire Rating (BS476–part22)	75 mm / 80 mm : 120 mins FRP; 100 mm / 150 mm : 240 mins FRP		80 mm : 120 mins FRP; 100 mm / 150 mm : 240 mins FRP
Sound Insulation (BS EN ISO140-3:1995)	75 mm : STC 38; 80 mm : STC 37 ; 100 mm : STC 41; 1150 mm : STC 44;		80 mm : STC 42 ; 100 mm : STC 46 ; 150 mm : STC 51
Surface Appearance	Smooth ; Tolerance ± 1 mm ( No plastering and slim coat required on AUGREEN Block wall)
Physical Appearance	Solid block; tongue and groove profiles on all sides
Tongue and Groove	4 sides rounded type
Compressive Strength	≥ 5 MPa		≥ 14 MPa
Bonding Agent (BA)	Gypsum-based adhesive
Water Resistance	Not Applicable	Water absorption in weight < 1% *H1 Class 0.43%	Not Applicable	Water absorption in weight < 1% *H1 Class 0.43%
Country of Origin	China

*Sound insulation can be achieved from 45dB – 66dB by using different "Double Shell" combinations.

*Maximum wall height does not require steel stiffener support which is proved by DIN standard and ICE calculations.

Coverage : 2.0 -4.5 kg/㎡

Thickness : 0-3 mm

Working Time : Approximately 60 minutes

Packing : 20 kg/ bag

Compressive Strength : 5 – 7 MPa

Tensile Strength : 1.4 MPa

Bending Stress : 0.7 MPa

Shear Stress : 1.4 MPa

Test Reports

AUGREEN Block Wall System have passed a range of tests and obtained numbers of certifications to ensure its quality and safety.

A. RED-Fire Test Report of 80mm

B. RED-Fire Test Report of 100mm

C. A+A Acoustic Test 80mm thick with 37 STC

D. A+A Acoustic Test 80mm thick with 41 STC

E. Compressive strength

For further information regarding the test reports, please contact CaSO at info@caso.com.hk
